INDEX
Nine service lines with reference designations. Each has a written scope, a typical programme, and a list of what you hold at handover. The codes are the same ones we use on drawings and proposals.
How to read this
Every service carries a reference code, from MECH-01 to MECH-09. It appears on the service page, in the footer schedule, on the proposal form, and on the drawings we issue. If you quote a code back to us, we know exactly what you mean.
MECH-01
Single-contract mechanical design-build. We run the load calculation, select the equipment against it, design the distribution, fabricate, install, and commission the result.
MECH-04
Condensing boiler plant, hydronic distribution and radiant floor. Designed around return water temperature, because a condensing boiler that never condenses is an expensive non-condensing boiler.
MECH-05
Duct design and fabrication to SMACNA and ACCA Manual D. We design to a stated friction rate, fabricate in our own shop, seal to the leakage class we specified, and test it.
MECH-07
Preventive maintenance on a written schedule with recorded readings, so equipment condition is a trend line rather than an opinion. Priority response and after-hours coverage for agreement holders.
MECH-02
Packaged rooftop unit replacement and new installation, from 3 to 50 tons. Curb adaptation, structural check, economizer setup, IEER-driven selection and gas train commissioning.
MECH-03
Variable refrigerant flow design and installation, including heat recovery. Line set sizing, refrigerant concentration limits, branch controller placement and the controls integration that makes VRF worth the money.
MECH-06
BAS and BMS work on BACnet MS/TP and BACnet/IP. Sequences of operation written in plain language first, then programmed, then verified point by point against the written sequence.
MECH-08
Commercial mechanical contracting across offices, light industrial, multifamily and tenant fit-out, from a single rooftop changeout to a full plant replacement.
MECH-09
Residential heating, cooling and ventilation. Every system starts with a room-by-room Manual J, because the house you have is not the house the rule of thumb assumes.
Our shop on Fox Street runs a coil line and a plasma table. That is not a boast about equipment, it is the reason the transition on the drawing is the transition that arrives on site, rather than a stock fitting plus improvisation at height.
It also means we can build a curb adapter for a specific unit on a specific curb in days, which is what makes single-weekend rooftop changeouts possible.
Ductwork engineering
Send us the building, the equipment and the complaint. You get a written response with the load we would run, what we would measure first, and a range before anyone visits.
Or call (303) 555-0148. Mon to Fri 07:00 to 17:00.
